Cioks DC10 10 Isolated Outlets Pedalboard Power Supply

DC10 is a multi-output power supply for effect pedals based on a toroidal transformer. It has 10 regulated and well-filtered DC outlets configured in 8 isolated sections. With a total of 1.600mA it’s a perfect solution for bigger rigs with DC pedals only.

The three powerful sections with 400mA each will power pedals with special requirements like Strymons, Eventides, TC Electronic Nova-series pedals or TC Helicon pedals, Moogerfoogers, Radial Tonebone pedals or others without the need of special cables. Selectable with a switch DC10 offers voltages 9, 12 and 15V, and combined with the included Stack Flex or Series adapter Flex also 18 and 24V. The first 4 isolated outlets offering 4x100mA are perfect for standard 9V low current pedals.

• Outlet 1-4: 9V DC / 100mA each
• Outlet 5-6: 9 or 12V DC / 200mA each*
• Outlet 7-8: 9 and 12V DC / 400mA
• Outlet 9-10: 9 and 12 or 15V DC / 400mA
• Size: 158x98x35mm (excl. detachable rubber feet)
• Weight: 1,1kg
• Warranty period: 5 years worldwide

* can be merged into a 400mA section
